Product Description
GIUNO ULTRA BT A Hydraulic Swing Gate Operator
The Giuno Ultra is a 24v hydraulic swing gate operator built for intensive use. This hydraulic gate opener is suited to industrial and residential use as well as multi-resident sites.
Hydraulic Gate Opener Available in Two Models
There are two models available, the A20 and A50. The A20 model is suitable leafs up to 2 metres and up to 300kg and the A50 model is suitable for 5 metres* wide and up to 800kg*.
24V Hydraulic Gate Opener Features
The Giuno Ultra hydraulic gate opener is suitable for swing gate leaves weighing up to 300KG and as large as two metres wide. This BFT swing gate opener also features built-in obstacle detection through the exclusive D-Track Torque management system.
Easy to Program Hydraulic Swing Gate Operator
The Giuno Ultra BT A Hydraulic Swing Gate Operator control unit comes with a display, making it incredibly easy to program. With U-Link, you will also be able to connect this hydraulic swing gate opener system with other devices via bluetooth, RS-485, and TCP/IP.
Reliable Swing Gate Opener
The GIUNO ULTRA A is a swing gate opener that offers precision manoeuvring and positioning while also being incredibly reliable, and resistant to dust, water, and ice. With D Track technology, the GIUNO ULTRA A hydraulic swing gate opener is able to adjust the level of thrust in order to operate in order to guarantee safety and perfect functionality.
Installing a Giuno Ultra is straightforward with our clear yet detailed installation manuals
Download our Giuno Ultra installation manual for further information.
* Although the Giuno Ultra BT A50 supports a maximum leaf length of 5m and maximum gate weight of 800kg, please be aware that at 800kg, the maximum leaf length is 2m. On a 5m gate leaf, the maximum gate weight is 300kgs. Please refer to the instruction manual for more information.
| Giuno Ultra BT A20 | Giuno Ultra BT A50 | |
| Power supply | 24V | 24V |
| Gate leaf length |
2m |
2m (Max. weight 800kg) 5m (Max. weight 300kg) |
| Max leaf weight | 300kg | 800kg |
| Control panel | THALIA P | THALIA P |
| Cycle time | 14 sec | 20 sec |
| Impact reaction | D-Track | D-Track |
| Frequency of use | Very intensive | Very intensive |
| Protection rating | IP55 | IP55 |
